Mornsun LIF240-10B48R2S AC/DC 240W DIN-Rail Power Supply
Mornsun LIF240-10B48R2S AC/DC 240W DIN-Rail Power Supply
In stock
Regular price
Rs. 6,218
Regular price
Rs. 8,495
Sale price
Rs. 6,218
Unit price
/
per
You save Rs. 2,277
Incl. GST (No Hidden Charges)
Currently, people are actively checking out this product.
Submit your Bulk Enquiry Here
Contact form
- Universal input voltage of 85-264VAC or 120-370VDC
- Accepts AC or DC input (dual-use of same terminal)
- Operating ambient temperature range of -40℃ to +70℃
- High efficiency and high reliability
- Built-in active PFC function
- 150% peak load output for 3 seconds
- LED indicator for power on
- Output short circuit, over-current, over-voltage, over-temperature protection
- Safety according to IEC/UL62368, UL508, EN61558
This product is not available for store pickup. Apologies for the inconvenience caused
Mornsun LIF240-10B48R2S AC/DC 240W DIN-Rail Power Supply
The LIF240-10B48R2S is a 240W AC/DC power supply that provides a 48V output voltage at 5A current. It is designed for use in industrial control equipment, machinery, and other industrial equipment. The power supply has a compact and lightweight design, making it easy to install and use. It also has a high level of stability and immunity to noise, making it ideal for use in harsh environments.
Features:
- 240W output power
- 48V output voltage
- 5A output current
- Compact and lightweight design
- High level of stability and immunity to noise
- Compliance with international IEC/EN/UL62368, UL61010 standards for EMC and safety
Note:
- Unless otherwise specified, parameters in this datasheet were measured under the conditions of Ta=25℃, humidity<75%RH with nominal input voltage and rated output load
- The room temperature derating of 5℃/1000m is needed for operating altitude greater than 2000m
- All index testing methods in this datasheet are based on our company's corporate standards
- In order to improve the efficiency at high input voltage, there will be audible noise generated, but it does not affect product performance and reliability
- The out case needs to be connected to the earth ( )of system when the terminal equipment in operating
- The output voltage can be adjusted by the ADJ, clockwise to increase
- Our products shall be classified according to ISO14001 and related environmental laws and regulations and shall be handled by qualified units
- The power supply is considered a component which will be installed into the final equipment. All EMC tests should be confirmed with the final equipment
Package Includes:
1 x Mornsun LIF240-10B48R2S AC/DC 240W DIN-Rail Power Supply
Specifications
Output power | 240W |
Output voltage | 48V |
Output current | 5A |
Isolation voltage | 3000VAC |
Dimensions | 100 x 60 x 180mm |
Weight | 1.5kg |
